ZEBRA – ZT230TT Thermal Transfer ID Card Printer

Description

• 203 dpi @ 6 ips
• 32-bit 400 MHz, 128 MB RAM / 128 MB Flash
• Icon-based LCD multilingual graphical user interface & full function keypad
• Rugged all-metal case for long-lasting use
• Thermal Transfer core-to-core ribbon handling system
• Ribbon width: 1.57″ to 4.33″
• Max. ribbon length / roll size: 984 ft. / 2.70″ OD on a 1.00″ core
• Thin film printhead w/ E3 Element Energy Equalizer
• Dual media sensors, transmissive & reflective sensing technology, selectable through software or front panel
• Side-loading metal print mechanism w/ head-open lock withstands general wear & tear & facilitates media loading
• Robust gold user touch points simplify operation by directing user to key areas for adjustment
• Space saving design w/ unique bi-fold door (requires 4.00″ of opening space)
• Tool-less platen & printhead removal for easy cleaning & replacement
• Supports 10/100 Ethernet networks internally integrated option that enables the use of ZebraLink WebView & Alert features
